BoMHTML parameters
datasheet_as_link : [string] (default:
'') [case insensitive]Column with links to the datasheet.generate_dnf : [boolean] (default:
true) Generate a separated section for DNF (Do Not Fit) components.logo : [string | boolean] (default:
'') PNG/SVG file to use as logo, use false to remove. Note that when using an SVG this is first converted to a PNG using logo_width.title : [string] (default:
'KiBot Bill of Materials') BoM title.col_colors: [boolean] (default:true) Use colors to show the field type.digikey_link: [string | list(string)] (default:'') [case insensitive]Column/s containing Digi-Key part numbers, will be linked to web page.extra_info: [string | list(string)] (default:'') Information to put after the title and before the pcb and stats info.hide_pcb_info: [boolean] (default:false) Hide project information.hide_stats_info: [boolean] (default:false) Hide statistics information.highlight_empty: [boolean] (default:true) Use a color for empty cells. Applies only when col_colors is true.lcsc_link: [boolean | string | list(string)] (default:'') [case insensitive]Column/s containing LCSC part numbers, will be linked to web page. Use true to copy the value indicated by the field_lcsc_part global option.logo_width: [number] (default:370) Used when the logo is an SVG image. This width is used to render the SVG image.mouser_link: [string | list(string)] (default:'') [case insensitive]Column/s containing Mouser part numbers, will be linked to web page.row_colors: [RowColors parameters] [list(dict)] (default:[]) Used to highlight rows using filters. Rows that match a filter can be colored. Note that these rows won’t have colored columns.style: [string] (default:'modern-blue') Page style. Internal styles: modern-blue, modern-green, modern-red and classic. Or you can provide a CSS file name. Please use .css as file extension.
.
